Quick Details

  • Condition: New
  • Usage: Water Pump
  • Fuel: Diesel
  • Stroke: 4 Stroke
  • Cylinder: Multi-cylinder
  • Cold Style: Water-cooled
  • Start: Electric Start
  • Place of Origin: Tianjin, China (Mainland)
  • Brand Name: LOVOL
  • Model Number: 1000 SERIES
  • Dimension(L*W*H): 1186*688*940
  • Weight: 460-700
  • Certification: CE and ISO
  • Warranty: 1 year or 1000 hours
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Speed: 1500/1800/2200r/min
  • Color: Depends
  • Engine fuel system: in-line fuel injection pump
  • Lubricating system: Spin-on full oil filter
  • Cooling system: gear driven water pump and radiator
  • Under frame base: optional
  • Mounting: Front engine mounting bracket

Packaging & Delivery

Packaging Details in wooden case
Delivery Time in one month
Parameter
Item1003-3Z1003-3TZ1004-4Z1004-4TZ1006-6TZ1006-6TAZ1106C-P6TADP1A
Cylinder number3344666
ModelPressurised water; In-line; 4 stroke; direct injection; dry cylinder liner
Induction systemNaturally aspiratedTurbochargedNaturally aspiratedTurbocharged Turbocharged Turbocharged Air to air aftercooledTurbocharged Air to air aftercooled
Borexstroke(mm)100x127100x127100x127100x127100x127100x127100x127
Displacement(L)2.992.993.993.995.985.985.98
Compression ratio16.5:117.5:116.5:117.5:117.5:117.5:117.5:1
Rated power(kW)1500r/min28444065.792.3121----
1800r/min30504475.6108130169
2200r/min-------507592135---
Governing<=10%<=10%<=10%<=10%<=10%<=10%<=10%
Weight(kg)460463502522666698875
Electric systemStandard configuration 12V.optional 24V
Overall dimensions AxBxC(mm)1186*688*9401186*688*9401250*706*9401250*706*9401520*708*11001600*800*10501803*911*1234



Remarks: Engine with 1500rpm, 1800rpm have 10% power reserve for water pump application. Engine with 2200rpm no need to have 10% power reserve, customers can use this power directly for water pump application.



Product Advantage
  • The engine can be easily started at -10without preheating device; and for temperature down to -25with preheating device;
  • With the radiator and independent fan drive, the engine is suitable for operation in ambient temperature up to 50(open type)
  • The instrument control box, with the warning function of high water temperature, low oil pressure and over-speed stop, makes operation more convenient and reliable.
  • Convenient for the customers; own installation, the air cleaner, radiator and underframe can be followed to assemble. And also the clutch can be applied according to the need of the customer.


Packaging & Shipping



The engine will deliver from Tanjing Port in China.

Engine will be packed by wooden box and spare parts by cartom.





Our Services

Since Gen-set reach the agreed destination,its main parts will be guaranteed within 12 months or 1000 hours(subject to the date which comes first.).We take charge of all troubles caused by Gen-set’s fault and repair according to the regulation stipulated by original plants.Factors not accordance with the regulation of original plants such as fragile parts,daily consumed components,wrong operating,lack of maintenance are not included in the quality guarantee.





Certifications



Company Information



Holly Enterprise Elec-Mech Equip. (Beijing) Co., Ltd. (hereinafter referred to as Holly E.) is an export trade company specialized in mechanical and electrical equipments. Holly E. was established in 2007 with registered capital of RMB5, 000,000, which has independent right of exporting (except for the sale of franchise).



Holly E. is mainly engaged in import and export of electrical &mechanical equipments and vehicles,which are sold to Europe, the Middle East, North America, South America, Southeast Asia and other markets.Main products: engine, generator set, alternator, electromotor, truck, city bus and inter-city bus.



Since established, Holly E. is operating in good conditions, having outstanding performance and keeping steady growth.



For several years since set up, our company is operating in accordance with international norms. On the equality and mutual benefit corporation bases, we make extensive exchanges with foreign customers and corporate with them actively in various forms of economic trade, which make our products taking a position in the international market.
